13 5/8 inch 5K BOP Stack

BRAND NEW with Warranty! Complete BOP Stack, Annular, Single or Double with Drilling Spool, BOP Handling System, BOP Control System, Spare RAMS available.

Annular Blowout Preventer Size: 13-5/8” x 5000PSI, type UZD 03, Working pressure (bar or psi)5000 psi, Annular ID (mm or in)13.625 in, Top connection STUDS 13 5/8X 5K psi, Bottom connection FLANGE 13 5/8X 5K psi, Pipe rams.

Single or Double Ram Blowout Preventer: 13-5/8” x 5000 psi type UZD 02, Ram(s) type and size5″, 4″ and 3-1/2″ Pipe rams & Blind rams, Working pressure (bar or psi)5000 psi, Top connection STUDS 13 5/8″ X 5K psi, Bottom connection STUDS 13 5/8″ X 5K psi, Blind rams / shear blind rams.

BOP handling system, BOP test stump – working pressure (bar or psi)Yes, working pressure 15000 psi, Digital or chart pressure recorder.

Spare rams sizes available: 2 3/8″, 2 7/8″, 3 1/2″, 4″ , 5″

Drilling Spool Specifications: Drilling spool adapters available, ID (mm or in)YES, ID= 343mm, Working pressure (bar or psi)5000 psi, Top connection13 5/8″ X 5K, Bottom connection 13 5/8″ X 5K, Outlet size 4 1/16″ / 2 1/16″, Outlet connection 4 1/16″ X 5K / 2 1/16″ x5K

BOP Control System Specifications: Type Pneumatic, Manufacturer REPEDE, Pressure5K psi

Choke manifold Specifications: Size (mm or in) and working pressure (bar or psi)3 1/8″ X 5K psi, Quantity of valves 11, Quantity of chokes 2, Choke types (manual/hydraulic) 1 manual / 1 hydraulic, Remote choke panel, Remote choke operation, Choke line ID4″, Line working pressure 5K psi, Kill Line ID2″, Line working pressure 5K psi

Message us below for a price quote
