Equipment Summary

Price : Price on Request
Type : Equipment For Sale
Date : December 8, 2023
Make : AKER
Model : DDM-650L-AC
Year : 2017
Condition : New
Warranty : No
Location : Italy, Piacenza

Description

Un-Used Surplus NEW 1150HP Aker Top Drive. Priced to Sell FAST, don’t miss out! Stored inside and properly preserved. We had two of these, only one left, don’t miss out!!!

DRILLING PERFORMANCE: Torque continuous 83 450 [61 541] Nm [Ft.lb], Torque intermittent 107 400 [79 200] Nm [Ft.lb], Torque @ Max. Speed 28 500 [21 020] Nm [Ft.lb], Speed cont. @ max. Torque 93 rpm, Speed max. 240 rpm, Hoisting capacity (static) 650 sh.ton
LIFTING PERFORMANCE: Swivel & Gearbox Drilling load path – lower main shaft connection limited 650 [589,7] Sh.T. [mT], Triping load path – outside lower main shaft connection 650 [589,7] Sh.T. [mT], Intermediate Sub Above 650 [589,7] Sh.T. [mT], Upper IBOP Above 650 [589,7] Sh.T. [mT], Lower IBOP Above 650 [589,7] Sh.T. [mT], Saver Sub Dependent on type Sh.T. [mT], Connection links 650 [589,7] Sh.T. [mT], Link hanger 650 [589,7] Sh.T. [mT]
RECENT UPDATE/INSPECTION: In August the owner sold the other top drive and did an inspection to check the status of both units. Both units were stacked in one of their covered facilities, under preservation packaging. Additionally they performed tests to check the electrical insulation of the Top Drive with the Megger and a borescope inspection for gear corrosion, both with positive results.

If you have Questions, would like to Request a Price or Schedule a Site Inspection, Message us Below
