JDR Thermoplastic Umbilical

🤑PRICE DROP🤑Un-Used Surplus New JDR Electro/Hydraulic 9.2km Thermoplastic Umbilical – 8 x hose and 2 x 6mm2 LV, Umbilical Termination Assemblies (UTA). 300t capacity reel included in package. ‘Reel Dimensions’ 300 metric ton capacity. This unit is NOW priced at $1.3 million usd.

Design Depth: 200m

Length: 9166m

Design Temperature: -5degC to +40degC

Diameter: 127mm (±2.5mm)

Umbilical Weight: 256,400 kg

Umbilical Hardware: 4,480 kg

Reel (Inc. Partition & Cradle): 39,440 kg

Skid (Approx.) Beam & Ramp: 1,330 kg

Reel Dimensions (LxWxH) (9820mmx6030mmx9755mm) Length: 11280mm with the UTA protruding

Design Life: 30years

Composition

Functional Lines: 2 off 1/2” 345 Bar Thermoplastic Hose, 2 off 3/8” 690 Bar Thermoplastic Hose, 3 off 3/4” 517 Bar Thermoplastic Hose, 1 off 1/2” 517 Bar Thermoplastic Hose, 2 off 4 x 6mm^2, 0.6/1.0 (1.2) kV twisted quad cable

Filler Elements: Polypropylene Rope Fillers

Armour Bedding Material: High Density Polyethylene

Strength Member Material: 2 Layers of contra helically applied GSW

Outer Serving Material: High Density Polyethylene

Message us below if you are interested in purchasing or if you have any questions
