Equipment Summary

Price : Price on Request
Type : Equipment For Sale
Date : September 28, 2022
Make : Mayhew
Model : 1400
Year : 2012
Condition : Used (like new)
Warranty : No
Location : Abu Dhabi

Description

All Terrain Water Well Drilling Rig, DSM/Mayhew 1400, Currently mounted on a 2012 Peterbilt-357 6X6 with just 2000 miles in like-new condition!

Specifications :
Kelly 3 3⁄4(95mm) diax23fr(7m)lg with three 1 in(25.4mm) drive pins
5×6 Gardner Denver Mud pump model FGAXG
Sulliar air compressor: Model DC 500 100-200/100MOD. 13
Rotary Table: Model DSM/Mayhew RT 7.5, Standard opening – 7 1⁄2 in (191mm), Frame opening with table retracted 16 in (406mm)
Transmission in excellent condition
Drawworks: Model DSM/Mayhew 24m, Single line pull (bare Drum ) 10000lb( 4536kg), Typical line speeds 310ft/min(94mm/min), Spooling capacity (each drum) 270 ft(82m) 5/8in (16mm), No of drums 2
Maximum Capacity: Mast 35000lb (15876kg), 2 in swivel (at 100 rpm) 32800lb (14878kg), TB-10 traveling block 20000 lb (9072 kg), 24M Drawworks (single line pull, Bare Drum 10000lb (4536kg ) 24M Sandreel (single line pull, Bare Drum 10000lb (4536kg)

➡ Additional Photos

Message us below for a formal price quote or to schedule a site inspection
